Product information “RAZOR T5”
RAZOR – the light module
Wherever aquariums or terrariums need to be illuminated under difficult conditions, and need to be particularly splash proof, our light module RAZOR is the perfect solution. The lighting casing consists of a silver anodized one-piece aluminum profile. This casing incorporates, in an extremely protected way, the entire electronics, including the electronic ballast gear. The premium-grade anodised surface provides optimum light reflection and is resistant even against aggressive salt-water. All sockets and sealing surfaces are also water-proof and equipped with additional neoprene sealing
Technical Details
Details RAZOR RAZOR
60 cm RAZOR
90 cm RAZOR
120 cm RAZOR
150 cm
Dimensions
L x W x H
595 x 145 x 47 mm
895 x 145 x 47 mm
1195 x 145 x 47 mm
1495 x 145 x 47 mm
Equipment/Power
RAZOR dual
RAZOR dual, dimmable*
2 x 24 Watt T-5
2 x 24 Watt T-5
2 x 39 Watt T-5
2 x 39 Watt T-5
2 x 54 Watt T-5
2 x 54 Watt T-5
2 x 80 Watt T-5
2 x 80 Watt T-5
Weight
1,46 kg
1,68 kg
2,08 kg
2,70 kg
Connection cord
~ 150 cm
~ 150 cm
~ 150 cm
~ 150 cm
Recommendation
marine/tropic
marine/tropic
marine/tropic
marine/tropic
GIESEMANN lights are suitable for the use of T-5 fluorescent tubes. For technical reasons, the use of LED tubes of similar design is not recommended, as this would invalidate any warranty claim.
*The light modules are also available in a dimmable version. The dimmable light bars are equipped with an additional data cable (Western connection, approx. 150 cm) or, on request, with a five-pole cable and 5-way plug.
Delivery
RAZOR
RAZOR
60 cm
RAZOR
90 cm
RAZOR
120 cm
RAZOR
150 cm
T5 light
1
1
1
1
Power cord
1
1
1
1
EU-Version
US-Version
EU-“SCHUKO” plug
US-plug
EU-“SCHUKO” plug
US-plug
EU-“SCHUKO” plug
US-plug
EU-“SCHUKO” plug
US-plug
Single reflectoren inlc. clips
2
2
2
2
Power
EU-Version: 220-240V|50 Hz
US-Version: 110V|60 Hz
EU-Version: 220-240V|50 Hz
US-Version: 110V|60 Hz
EU-Version: 220-240V|50 Hz
US-Version: 110V|60 Hz
EU-Version: 220-240V|50 Hz
US-Version: 110V|60 Hz
Manual
1
1
1
1
